Hailubida Auto Parts Co., Ltd.

Maximum driving voltage: <50V

Working current：<100mA

Withstand voltage of 2kDVC substrate:

Working temperature：-40°C~ +85°C

Rebound time: 6ms

Functional Description:

1. Membrane switch;

2. When the seat is unoccupied, the sensor is in the open state, i.e., resistance >10MΩ;

3. When the seat is occupied, the sensor is in the closed state, i.e., resistance <150Ω.
